UV DTF Transfer Gang Sheets

A UV DTF gang sheet is one 22 inch wide sheet of UV transfer film packed with as many sticker designs as you can fit on it. You upload your designs, arrange them on the sheet, and we print them together; when it arrives, you cut the designs apart with scissors and apply each one by hand. No heat press is involved at any point: UV DTF is a peel and stick transfer for hard, smooth surfaces like tumblers, glass, metal and acrylic, not a heat transfer for fabric.

Quick Summary
  • One sheet, many designs: a gang sheet prints your whole batch together and you cut it apart yourself.
  • UV film is 22 inches wide, in lengths from 12 to 168 inches, at $0.72 per inch of sheet length, at every length.
  • The online builder is free and needs no account: upload PNG, PDF or AI files at 300 DPI and arrange them in the browser.
  • UV DTF applies by hand to hard, smooth surfaces. For shirts and fabric, use regular DTF gang sheets instead.
  • Orders and print-ready files confirmed before 1:00 PM ET, Monday to Friday, go into production the same day.

In this article

What Is A UV DTF Gang Sheet?

Gang sheet means several designs printed together on one sheet instead of each design on its own piece of film. With UV DTF, that sheet is 22 inch wide film carrying UV cured ink with an adhesive layer, so once you cut a design out, it is a peel and stick transfer. You apply each piece by hand to a clean, dry, hard, smooth surface.

UV DTF is a different product from regular DTF: regular DTF is for fabric and needs a heat press, while UV DTF is for hard goods and goes on with firm pressure from your fingers or a squeegee. The background is in what UV DTF transfers are, and the side by side is in UV DTF vs DTF.

After you apply a design, wait 24 hours before the first wash. Wash the item by hand only; do not use a dishwasher or leave it soaking for long periods. Do not put decorated drinkware in a microwave. Outdoor use is not recommended, because prolonged sunlight and weather can break down the adhesive over time.

One Design Or Many: How To Get The Most From A Sheet

Every UV order prints on a 22 inch wide sheet, at least 12 inches long, so even a single design arrives on a sheet. What changes the math is how much of that sheet you fill:

  • Your order mixes designs. A sheet can carry wraps, logos and small decals together, with no per design charge.
  • You want copies. Duplicate the same design across the sheet and cut the run apart at once.
  • You watch cost per sticker. You pay for the inches of sheet you use, so a tight layout is what brings the cost of each decal down. By our own layout math, about 45 designs of 2 x 2 inches fit on a 12 inch sheet, roughly $0.19 each before shipping.

The tradeoff is labor: a gang sheet arrives as one piece and you do the cutting with scissors. For a handful of pieces that goes fast; for very large runs, plan the time.

Illustration of a UV DTF gang sheet with one design cut out as a rectangle, scissors beside it.

How The UV Gang Sheet Builder Works

The builder on our site is free to use and needs no account. This is the flow, as it works today:

  1. Pick your sheet length. UV runs on 22 inch wide film, in lengths from 12 to 168 inches. The price updates by the inch as you go.
  2. Upload your artwork. PNG, PDF or AI at 300 DPI with a transparent background. Upload as many separate files as you want; the builder treats each one as a design you can move, scale and repeat.
  3. Arrange your designs. Drag each design onto the sheet, then resize, rotate and duplicate. The builder packs designs close together to reduce empty space. You pay for the sheet length you choose, with a minimum length of 12 inches.
  4. Send it to production. No account to create and no quote to wait for. If you already laid out your own sheet, upload the finished PNG and we print it exactly as submitted.
Illustration of sticker designs nested tightly on a long sheet of UV DTF film.

You can start from the UV gang sheet builder or from the UV DTF transfers product page.

What A UV Gang Sheet Costs

UV DTF is $0.72 per inch of sheet length, at every length, with no minimums, no setup fees and no charge for using the builder. The rate is the same on your first sheet and your fiftieth:

Sheet Length (22 in wide) Price
12 inches $8.64
24 inches $17.28
60 inches $43.20
96 inches $69.12

You can order a single sheet; the shortest sheet is 12 inches long. Orders and print-ready files confirmed before 1:00 PM ET, Monday to Friday, go into production the same day at no extra cost. Every order ships from Miami to all 50 states, and ground shipping is free on orders of $99 or more.

Layout Tips For UV Sheets

Building for UV is not identical to building for fabric DTF. Three differences worth planning around:

  • The film is 22 inches wide, not 24. A layout built for our textile custom gang sheets is 24 inches wide, so rework it to fit within the 22 inch width of a UV sheet.
  • Curved surfaces want smaller pieces. A design that wraps a tumbler applies cleaner when it is split into sections than as one long piece. The application itself, including how to place wraps without bubbles, is covered in how to apply UV DTF cup wraps.
  • Leave room to cut. The builder packs designs close together, but each piece still needs enough clear film around it to cut and handle comfortably. On tapered or curved items, trim the extra film close to the design to help keep the edges from lifting.
Illustration of a UV DTF wrap applied around a stainless steel tumbler, with a felt squeegee beside it.

One file rule that sends orders back for a fix: for UV DTF we need a fully transparent background and fully opaque colors, so we don't accept semi-transparent effects like soft shadows, glows or fades to transparent. The white layer printed behind your colors needs to be solid, and where it is not, the transfer can break. Gradients between solid colors are fine.

Frequently Asked Questions

Do I Need Design Software To Use The Builder?

No. Upload the designs you have and arrange them in the browser: move, resize, rotate and duplicate until the sheet is packed. If you prefer to lay out the sheet in your own software, upload the finished PNG and we print it exactly as submitted.

Can I Put Different Designs On One Sheet?

Yes, as many as fit. There is no per design charge, so mixing wraps, logos and small decals on one sheet costs the same per inch as repeating one design.

Does Using The Builder Cost Extra?

No. The rate is $0.72 per inch of sheet length whether you arrange the sheet in the builder or upload it ready made, and there are no minimums and no setup fees.

Do I Need A Heat Press For UV DTF?

No. You apply UV DTF by hand, with no heat press, no curing time and no UV lamp on your side. Regular DTF is the product for fabric, and that one needs a heat press. The full comparison is in UV DTF vs DTF.

What Files Does The UV Builder Accept?

PNG, PDF or AI at 300 DPI with a fully transparent background and fully opaque colors. Leave out semi-transparent effects such as soft shadows, glows or fades to transparent: the white layer printed behind your colors needs to be solid, and where it is not, the transfer can break. Gradients between solid colors are fine.

Can UV DTF Gang Sheets Go On Shirts?

No. UV DTF does not bond to fabric. It is made for hard, smooth surfaces like tumblers, glass, metal and acrylic. For shirts and other textiles, order regular DTF gang sheets, which apply with a heat press.

Build Your UV Gang Sheet

Pick a length, upload your designs, and watch the price update by the inch as you arrange them. Start in the UV gang sheet builder, or read what UV DTF transfers are first if you are still comparing materials.

About the author

Jose Polanco

Content Editor, DTF Transfers Wholesale · Miami, FL

Jose edits the guides published by DTF Transfers Wholesale, a wholesale DTF and UV DTF printer based in Miami that prints in house and ships across the United States.

The builder flow, prices and file rules in this guide come from our live UV gang sheet builder and our UV DTF product page.

Originally published March 2, 2026. If something here does not match what you see in the builder or on your order, write to us.
